Chapter 5 Programmable Parameters
Evia HF / HF-T Technical Manual
PAGE 27
+/-
Minimum
Threshold
0.5 mV
Detection Hold-off Period
(DHP)
2x Step
Duratio
n
+/- Sensitivity
Threshold
from the previous event
Event
Detection
Pace
event
Atrium
DHP 120 ms
Step Duration 82 ms
Post Pace Event – Atrium -
Unipolar
Fixed value
Atrium – 1.0
mV
½
Fixed
value
Figure 13: Automatic Sensitivity Control for Atrial Unipolar Paced Events
Ventricular Pacing Overview
Table 5 shows a ventricular pacing overview and applies to bradycardia programming and Mode Switch
programming.
Parameter Range Default
Ventricular pacing BiV, RV BiV
Triggering OFF, RVs, RVs+PVC RVs
LV T-wave protection ON, OFF ON
Maximum trigger rate Auto, 90...(10)...160 ppm Auto
Initially paced
chamber
LV, RV LV
VV Delay after Vp 0...(5)...100 ms 0 ms
VV Delay after Vs 0 ms 0 ms
Table 5: Ventricular Pacing Parameters
Figure 14: Ventricular Pacing Parameter Screen
