Chapter 5 Programmable Parameters
Evia HF / HF-T Technical Manual
PAGE 33
AV Setting Low Medium High
15 ms 85 ms 125 ms 165 ms
50 ms 120 ms 160 ms 200 ms
75 ms 145 ms 185 ms 225 ms
100 ms 170 ms 210 ms 250 ms
120 ms 190 ms 230 ms 270 ms
130 ms 200 ms 240 ms 280 ms
140 ms 210 ms 250 ms 290 ms
150 ms 220 ms 260 ms 300 ms
160 ms 230 ms 270 ms 310 ms
170 ms 240 ms 280 ms 320 ms
180 ms 250 ms 290 ms 330 ms
190 ms 260 ms 300 ms 340 ms
200 ms 270 ms 310 ms 350 ms
225 ms 295 ms 335 ms 370 ms
250 ms 320 ms 360 ms 400 ms
300 ms 370 ms 410 ms 450 ms
350 ms 420 ms 450 ms 450 ms
Table 8: AV Hysteresis Settings
5.5.4.3 AV Repetitive Hysteresis
With AV Repetitive Hysteresis, the AV delay is extended by a dened hysteresis value after sensing
an intrinsic ventricular event. When a ventricular stimulated event occurs, a long AV delay is used for
the programmed number of cycles. (1 … 10). If an intrinsic rhythm occurs during one of the repetitive
cycles, the long duration AV delay interval remains in effect. If an intrinsic rhythm does not occur during
the repetitive cycles, the original AV delay interval resumes.
Figure 16: AV Repetitive Hysteresis
