Maintenance Instruction manual A400 / A400FB
8 - 6 6.054.98.5.10.06 en
8
Product holder 600 mm carriage
Fig. 46: Product holder
Loosen the star-grip handle on the car-
riage.
Lift out the holder casing in upwards di-
rection.
product support
Fig. 47: product support
Loosen star knob on guide element.
Remove product support.
Blade cover
Fig. 48: Blade cover
Place widely-spanned right hand on the
cover.
Use the left hand to unscrew the attach-
ment bolts on the triangular handle and
push out of center by applying pressure
to the bolts.
Tilt out the cover on to the span of your
hand, and remove upwards.
Do not muddle with covers from other
machines!
