AC Input Ratings (selectable via the line voltage receptacle switch):
115 Vac ± 10 % for 47 to 63 Hz
230 Vac ± 10 % for 47 to 63 Hz
Line voltage selection:
The line fuse is located in the space just below the input receptacle. To change
line voltage values first remove fuse holder and then remove tan colored fuse
bracket. The line voltage value is determined by value shown through the
window of the fuse holder. Please ensure correct insertion and fuse rating.
Fuse ratings:
Model 9120: 3.15A/250V for 115Vac, 2A / 250V for 230V
Model 9121: 3.15A/250V for 115Vac, 2A /250V for 230V
Model 9122: 5A/250V for 115Vac, 3.15A / 250V for 230V
Model 9123: 5A/250V for 115Vac, 3.15A / 250V for 230V
All fuses are type T (temporized) for high power up currents.
Cooling:
Fan cooled
Operating temperature:
32
°
to +104
°
F (0
°
to 40
°
C), <75% R.H. for full rated output.
Storage temperature:
-4
°
to +158
°
F (- 20
°
to + 70
°
C), <85%R.H. for storage environment.
Environmental conditions:
Designed for indoor use.
Net weight:
12.5 (5.6 kg)
Dimensions (H x W x D):
3.15 x 8.27 x 15” (8 x 21 x 38 cm)
Important note!
The technical specification are warranted for 32
°
to 104
°
F (0
°
to 40
°
C) with a
resistive load. Supplemental characteristics are not warranted. They are
determined either by testing or design.
