Rear Panel Description
On the rear panel of the power supply there are:
§
§ RS-232 interface connector
§
§ AC inlet
§
§ Power-line fuse-holder assembly
§
§ Rear output terminals.
+s
-s
+
-
The sensing terminals (+s and -s) are connected to the output terminals of the
power supply by jumpers.
For the power supply to work properly, the jumpers must be kept in that
position.
