Programming Ranges
The power supply parameters are programmed using command of SOURce
subsystem. Here are programming ranges, programming values for MINimum,
MAXimum, DEFault parameters and reset state:
Table 5: Programming ranges for voltage parameter
Voltage
parameters
Model
9120
Model
9121
Model
9122
Model
9123
Programming
range
0 to 30.5V 0 to 20.5V 0 to 30.5V 0 to 30.5V
MINimum 0 V 0 V 0 V 0 V
MAXimum 30.5 V 20.5 V 60.5 V 30.5 V
DEFault 0 V 0 V 0 V 0 V
Reset 0 V 0 V 0 V 0 V
Table 6: Programming ranges for current parameter
Current
parameters
Model
9120
Model
9121
Model
9122
Model
9123
Programming
range
0 to 3.05 A 0 to 5.05 A 0 to 2.55 A 0 to 5.05 A
MINimum 0 A 0 A 0 A 0 A
MAXimum 3.05 A 5.05 A 2.55 A 5.05 A
DEFault 0 A 0 A 0 A 0 A
Reset 3.00 A 5.00 V 2.5 V 5.0 A
Table 7: Programming ranges for OVP parameter
OVP
parameter
Model
9120
Model
9121
Model
9122
Model
9123
Programming
range
1 to 33 V 1 to 22 V 1 to 63 V 1 to 33 V
MINimum 1V 1V 1V 1 V
MAXimum 33 V 22 V 63 V 33 V
Reset 33 V 22 V 63 V 33 V
Important note!
Reset value for a parameter is the value after a *RST command or after
recalling Reset state.
