Recalling States in Front Panel Mode
To recall an operating state in front panel mode, you must follow the steps
described bellow:
1. Enter the Recall menu
By pressing Recall key, you enter the Recall menu.
By turning the knob, following options are displayed:
etc. (all 100 operating states are displayed)
2. Select the operating state
By using < > keys (to select the digit you modify by turning the knob) and
turning the knob all operating states stored in non-volatile memory are
displayed. An operating state is recalled by pressing Recall key when desired
state is displayed.
3. Recall the operating state
When Recall key is pressed, the selected operating state becomes the current
operating state of the power supply, after Done message is displayed.
01: State 1
