Port Status
When you set the LACP function on the switch, a Port Status overview for all LACP instances is enabled.
Web Interface
To display the LACP Port Status in the Web interface:
1. Click Configuration, LACP, Port Status
2. To set the switch to auto-refresh the information, check “Auto-refresh”.
3. Click “Refresh“ to refresh the LACP Port Status.
Figure 3-15. The LACP Status screen.
Parameter Description
• Port: The switch port number.
• LACP: “Yes“ means that LACP is enabled and the port link is up. “No“ means that LACP is not enabled or that the port link is
down. “Backup“ means that the port could not join the aggregation group but will join if other port leaves. Meanwhile its
LACP status is disabled.
• Key: The key assigned to this port. Only ports with the same key can aggregate together.
• Aggr ID: The Aggregation ID assigned to this aggregation group. IDs 1 and 2 are GLAGs while IDs 3-14 are LLAGs.
• Partner System ID: The partner’s System ID (MAC address).
• Partner Port: The partner’s port number connected to this port.
• Auto-refresh: Click auto-refresh to refresh the information automatically.
• Icon, upper right of screen (Refresh): Click to refresh the LACP port status information manually.
