EP600 Energy Storage System User Manual
12
Mode3
When the power grid is cut off , PV and battery will provide power to the load together.
Figure 2-3
Mode4
Battery can be charged by grid, the charging time and power can be set flexible in APP.
Figure 2-4
Solar panels
Public Grid
AC loads
B500 battery
BLUETTI APP
EP600
Solar panels
Public Grid
AC loads
B500 battery
BLUETTI APP
EP600
Green Energy
Public Grid Energy
Hybrid Energy
Green Energy
Public Grid Energy
Hybrid Energy
