6.2 B500 External ports description
Table 6-2
Connect port name
Connect port function
Remark
Inverter signal
connect port
( PCS Link )
Used to connect the inverter, only the top battery pack needs
to connect inverter.
Battery pack signal
input port
( PACK LinkIn )
When the battery is installed in a stack, it is used to connect
the battery pack signal of the previous battery
The output port, such as the inverter above, is not
connected.
Battery pack signal
output port
( PACK LinkOut )
When the battery is installed in a stack, the battery pack
signal used to connect the next battery, The input port,such
as the battery pack is the bottom one, then do not connect.
Positive output line
port
Used to connect other batteries’ Positive
output line port or connecting to an inverter
device BAT+ port.
Make sure
it's plugged
into place
Negative output line
port
used to connect other batteries’ Negative
output line port or connecting to an inverter
device BAT- port.
Make sure
it's plugged
into place
