Bluetti EP600 - B500

EP600 Energy Storage System User Manual
77
Standard & Authentication
Safety
IEC62109-1, IEC62109-2, EN62109-1,
EN62109-2
Grid Connections
VDE-AR-N4105, VDEV 0124-100
Emissions(EMC/EMI)
EN IEC 61000-6-1, EN/IEC 61000-6-3
RoHS
RoHS 2.0
IP65
IEC60529
Certifications
CE
B500
Item
Rating
Note
Battery Type
LiFePO4
LiFePO4 Cells
Battery Voltage
99.2V
3.2V×31
Rated Capacity
4960Wh
25℃,
Charge:
0.5C/3.6V/0.05C
Discharge: 0.5C/2.5V
Usable Capacity
4464Wh
90% DoD, 25℃,
0.5C charge and 0.5C
discharge.
Cell Overvoltage Protection
3.7V
Cell Undervoltage Protection
2.5V
Maximum Input Voltage
108.5V
3.5V×31
Minimum Output Voltage
86.8V
2.8V×31
Maximum Input Current
25A
The continuous input
current is affected by
temperature and SoC.
Maximum Output Current
50A
The continuous input
current is affected by
temperature and SoC.
