Bluetti EP600 - Working Mode

EP600 Energy Storage System User Manual
11
2.2 Working mode
The following are the general working modes of the EP600 energy storage system. According to
your configuration and layout condition to select the working mode.
Mode1
PV generate power to the load , the overflow power will charge the battery first, then output to the grid;
Figure 2-1
Mode2
When there's no PV output , battery will provide power to the load first, then grid provide power when
battery is in low power.
Figure 2-2
Solar panels
Public Grid
AC loads
B500 battery
BLUETTI APP
Green Energy
Public Grid Energy
Hybrid Energy
Fed into the public grid.
EP600
Solar panels
Public Grid
AC loads
B500 battery
BLUETTI APP
EP600
Green Energy
Public Grid Energy
Hybrid Energy
