EP600 Energy Storage System User Manual
4. B500 Battery Pack Introduction
4.1 B500 Product Information
The B500 energy storage battery system is designed for residential and small commercial uses.
Single pack rated capacity is 4.96KWh. It support 16 battery packs in parallel to meet capacity up to
80KWH.
The B500 battery management system adopts a multi-level architecture, which can detect the
voltage, current and temperature of the battery pack in real time during the charging and discharging
process. Accurately and efficiently realize the over-voltage, under-voltage, over-current, over-
temperature and under-temperature protection of the system.
The safety function of B500 control system adopts redundant design, which meets the functional
safety requirements and has good safety and stability.
4.2 Appearance Description
Appearance of B500 Battery Pack
Table 4-1
