EP600 Energy Storage System User Manual
24
11
MC4 assemble and disassemble tool
2
12
BAT- Input terminal plastic cover(Black)
1
13
BAT+ Input terminal plastic cover(Red)
1
14
M4*12 screw (8 fix BAT+/- terminal
cover、 6 AC junction Box)
14
15
M8*12 screw (Connect battery power
cable)
2
16
M6*12 screw(Fix bracket-wall screw)
2
17
M5*10 screw(4 fixed bracket-machine, 2
PV ground)
6
18
M4*10 screw(Fix the decorative covers
on both sides)
10
19
M8*60 Expansion bolt(Wall screw)
2
20
RNB3.5-5S TO terminal
AC connection terminal *10PCS
PV ground *2PCS
12
21
Battery power cable +
1
