2.2. PART NUMBER BREAKDOWN
Figure 2-1: M3452 Part Number Breakdown
BASE MODEL NUMBER
The base model number for all dynamic braking transistor modules is M3452.
CONTROL VOLTAGE RATING
The control voltage rating indicates the control voltage to the unit. This can be the
drive system AC line voltage or a different input voltage. This is indicated by a code
letter.
Note: Not all system voltages are available as control voltages.
Table 2-1: Control Voltage Rating
CONTROL VOLTAGE
RATING CODE
VOLTAGES
U
115 - 120VAC
L
230 - 240VAC
E
380 - 415VAC
H
460 - 480VAC
C
575 - 600VAC
BRAKING CURRENT RATING
The braking current rating indicates the maximum current level that can safely be
handled by the M3452 dynamic braking transistor module.
The braking current rating is indicated by a 3 or 4-digit number. For example, 300
indicates a braking current rating of 300 Amps maximum.
Table 2-2: Available Braking Current Ratings
AVAILABLE CURRENT RATINGS
(ADC)
200, 300, 600, 800, 1200, 1600
M3452
U
600
C
K6
-
R8PDP
BASE MODEL NUMBER
CONTROL VOLTAGE
BRAKING CURRENT
*DC BUS VOLTAGE
CHASSIS STYLE
CONTROL OPTION
-
