6. ENGINEERING DATA
6.1. RATINGS CHARTS
Table 6-1: Module Ratings: 230 – 240 VAC Drives (375 VDC Setpoint)
BASE
MODEL
NUMBER
CONTROL
VOLTAGE
BRAKING
POWER
(PEAK)
BRAKING
CURRENT
(PEAK)
BRAKING
CURRENT
(RMS)
DUTY
CYCLE
MINIMUM
RESISTANCE
FUSING
M3452-
U200LK6
115-120
VAC
100 HP
200 A
200 A
100%
1.90 Ω
FWP-200
M3452-
L200K6
230-240
VAC
M3452-
U300LK6
115-120
VAC
150 HP
300 A
300 A
100%
1.25 Ω
FWP-300
M3452-
L300K6
230-240
VAC
M3452-
U600LK6
115-120
VAC
300 HP
600 A
300 A
50%
0.63 Ω
A70QS600
M3452-
L600K6
230-240
VAC
M3452-
U800LK9
115-120
VAC
400 HP
800 A
400 A
50%
0.47 Ω
A70QS800
M3452-
L800K9
230-240
VAC
M3452-
U1200LK10
115-120
VAC
600 HP
1200 A
600 A
50%
0.32 Ω
A70QS800
M3452-
L1200K10
230-240
VAC
