User’s Manual
53
Table 6-5: Module Ratings: 690VAC Drives (1090 VDC Setpoint)
BASE
MODEL
NUMBER
CONTROL
VOLTAGE
BRAKING
POWER
(PEAK)
BRAKING
CURRENT
(PEAK)
BRAKING
CURRENT
(RMS)
DUTY
CYCLE
MINIMUM
RESISTANCE
FUSING
M3452-
U200YK6
115-120
VAC
300 HP
200 A
200 A
100%
5.50 Ω
A100P200
M3452-
U300YK6
115-120
VAC
440 HP
300 A
300 A
100%
3.60 Ω
A100P300
M3452-
U600YK6
115-120
VAC
875 HP
600 A
300 A
50%
1.95 Ω
A70QS600
M3452-
U800YK9
115-120
VAC
1170 HP
800 A
400 A
50%
1.40 Ω
A70QS800
M3452-
U1200YK10
115-120
VAC
1750 HP
1200 A
600 A
50%
0.91 Ω
A70QS800
M3452-
U1600YM14
115-120
VAC
2300 HP
1600 A
1200 A
75%
0.68 Ω
N/A
6.2. WATT LOSS
Table 6-6: Watt Loss
UNIT PEAK
CURRENT
CONTROL POWER
WATT LOSS
HEATSINK
WATT LOSS
200 A
55 W
500 W
300 A
55 W
750 W
600 A
55 W
750 W
800 A
55 W
1000 W
1200 A
55 W
1440 W
1600 A
55 W
2500 W
6.3. UL 508A SHORT CIRCUIT CURRENT RATING
When braking transistors are used with Underwriters Laboratories listed or recognized
drives, the short circuit current rating (SCCR) is determined by the SCCR rating of the
attached drive.
6.4. FUSE/CIRCUIT BREAKER SIZING AND RATING
Each module (except the 1600 Amp M14 chassis) comes equipped with its own
internal DC bus fuse. If the fuse happens to fail, it is not recommended to replace
the fuse and reapply power. Further damages could result. Consult Bonitron if
this situation arises.
If you wish to place fuses in your DC link, coordinate the fuse size with the proper wire
size used in your link as per local codes and regulations. Fast acting semiconductor
type fuses should be used.
