bonitron M3452 - Table 2-3: DC Bus Voltage Rating

User’s Manual
11
*DC BUS VOLTAGE
This code is used only if different from the control voltage rating.
Omit this position if control voltage is the same as nominal AC line voltage.
The DC bus voltage indicates the voltage regulation level of the DC bus if the control
voltage input does not correspond to the actual drive bus being controlled.
The DC bus voltage uses the codes L, E, H, C, and Y as shown in Table 2-3.
Table 2-3: DC Bus Voltage Rating
VOLTAGE
RATING CODE
VOLTAGES
(NOMINAL AC LINE / DC BUS TRIGGER LEVEL)
L
230 – 240 VAC Line / 375 VDC
E
380 – 415 VAC Line / 620 VDC
H
460 – 480 VAC Line / 750 VDC
C
575 – 600 VAC Line / 940 VDC
Y
690 VAC Line / 1090 VDC”
Nxxxx
Special (xxxx VDC)
Nxxxx is used only for custom trigger levels. Contact Bonitron before specifying
Nxxxx.
CHASSIS
The chassis code represents the chassis type and size of the dynamic braking
transistor module.
Table 2-4: Chassis Codes
CHASSIS
CODE
CURRENT
(AMPS)
TYPE
DIMENSIONS
(H” X W” X D”)
K6
200-600
Open Chassis
20.00 x 7.12 x 10.50
K9
800
Open Chassis
20.00 x 9.05 x 10.25
K10
1200
Open Chassis
20.00 x 10.00 x 10.50
M14
1600
Open Chassis
28.00 x 13.90 x 14.60
T10
1600
Open Chassis
30.60 x 10.12 x 19.20
CONTROL AND NETWORK OPTION
This code indicates the network protocol selected. See Table 2-5 below for a list of
available R8 options. Please contact Bonitron if you have any other special
requirements.
Table 2-5: Control Option Codes
CONTROL OPTION
CODE
DESCRIPTION
R8PDP
R8 unit with PROFIBUS comm module
R8EIP
R8 unit with EtherNet/IP comm module
