3. INSTALLATION INSTRUCTIONS
DANGER!
Installation and/or removal of this product should only be performed by a qualified
electrician in accordance with National Electrical Code or local codes and
regulations.
Proper installation of the model M3452 dynamic brake module should be done following
the steps outlined below. Be sure to refer to all other relevant system documentation as
these steps are performed. Please direct all installation inquiries that may arise during the
installation and start-up of this product to the equipment supplier or system integrator.
3.1. PRODUCT INSPECTION
Upon receipt of this product, please verify that the product received matches the
product that was ordered and that there is no physical damage to the unit. If the wrong
product was received or the product is damaged in any way, please contact the
supplier from which the product was purchased.
3.2. SITE SELECTION
The installation site for the module should be chosen with several considerations in
mind:
All units require adequate protection from the elements.
Adequate clearance should be allowed for easy access to terminals and
adjustments. This will facilitate inspection and maintenance.
Sufficient circulation of clean, dry air should be provided. Ambient temperatures
should not exceed +40°C (+104°F) nor be less than 0°C (+32°F) and non-
condensing. Ambient air should not be contaminated with harmful chemical vapors
or excessive dust, dirt, or moisture.
The unit will require a minimum clearance of six (6) inches above and below it to
allow for proper airflow for cooling. Avoid mounting the unit with its air intake near
heat sources.
3.3. MOUNTING
Once the installation site has been selected as outlined above, and the mounting holes
drilled and mounting studs or anchors installed, the dynamic brake module is ready to
be hung in position. Be sure all mounting hardware is tightened securely.
Refer to Section 6.4 of this manual to determine the correct mounting dimensions and
provisions for the unit.
