3 Technical data
Parameter Value
Supply voltage 380-415 V 2N/3N
Supply voltage 220-240 V
Frequency 50 Hz/60 Hz
Maximum power consumption 7.6 kW (4.4 kW)
Fuse protection/power supply 3 x 16 A
2 x 16 A
1 x 32 A
Dimensions (width x depth x height) 760 x 515 x 199 mm
Weight (incl. accessories/packaging) Approx. 23 kg
Cooktop
Power levels 1 – 9, P
Front cooking zone size Ø 210 mm
Front cooking zone power setting output 2300 W
3000 W
Rear cooking zone size Ø 175 mm
Rear cooking zone power setting output 1400 W
2100 W
Cooktop energy consumption
Cooking zone 1 (210 mm) 186.3 (Wh/kg)
Cooking zone 2 (175 mm) 177.2 (Wh/kg)
Cooking zone 3 (210 mm) 191.5 (Wh/kg)
Cooking zone 4 (175 mm) 177.2 (Wh/kg)
Total 183.1 (Wh/kg)
Extraction system (PURA)
Maximum flow volume 625.7 m
3
/h
Maximum static pressure 612.0 Pa
Power levels 1 – 9, P
Exhaust air connection BORA Ecotube
Recirculation system (PURU)
Maximum flow volume 579.6 m
3
/h
Maximum static pressure 545.1 Pa
Power levels 1-9, P
Recirculation connection (WxH) 433 x 126 mm
Recirculation filter (PURU)
Filter capacity 150 operating hours
Service life 1 year
Tab. 3.1 Technical data
Device dimensions PURA
515
760
257,5
444
255 120
340
Ø175
Fig. 3.1 PURA device dimensions top view
68
6
199
196,5
732
Fig. 3.2 PURA device dimensions front view
487
400
63
Fig. 3.3 PURA device dimensions side view
