7.6.4 Menu item 6: LED test
INFO With menu item 6 all LEDs in the individual touch
zones can be tested to ensure that they are
working.
Fig. 7.7 Menu item 6: LED test
Starting the LED test
Tap the slider zone
All indicators are displayed at 50 % brightness.
Tap any indicator you wish.
The selected indicator will be displayed at 100%
brightness.
Any other indicators can be tested by touch as
required.
Ending the LED test
The LED test will be automatically ended when there
has been no activity for 5 seconds.
or
Long press on the multi-function display.
The LED test is ended.
Move to another menu item or close the menu.
Fig. 7.5 Menu item 4: Duration of the automatic after-run
function
The current duration is displayed for 2 seconds.
Selecting the duration of the automatic after-run
function:
Tap the corresponding slider segment .
Move to another menu item or close the menu.
Menu item 5: Touch zone reaction speed
INFO The reaction speed of the touch zones can be set
using menu item 5.
Reaction speed
1
: slow
Reaction speed
2
: medium
Reaction speed
3
: fast
Fig. 7.6 Menu item 5: Reaction speed
The current reaction speed is displayed.
Selecting the reaction speed:
Tap the corresponding slider segment .
Move to another menu item or close the menu.
