The duration of the after-run function can be set in the
menu (10, 15 or 20 minutes). The default duration of the
after-run function is 20 minutes.
The after-run function is activated when the extractor
is switched off at the end of cooking.
Once the automatic after-run period has lapsed the
cooktop extractor switches itself off.
INFO BORA expressly recommend use of the cooktop
extractor after-run function.
Filter service display
The cooktop extractor filter service indicator is
automatically activated when the end of the activated
charcoal filter service life is reached (only in recirculation
mode).
F
is displayed in the multi-function display.
The filter service display is shown every time the
cooktop extractor is switched on and remains active
until the filter has been changed and the filter service
display has been reset (see Operation chapter).
The cooktop extractor can still be operated without
limitations.
INFO The components of the grease filter require
regular cleaning regardless of the filter service
indicator (see Cleaning and Maintenance chapter).
5.6 Cooktop functions
Cooktop power adjustment
The power levels are adjusted via the operating panel
by tapping or swiping movements on the touch slider.
Alternatively the power levels can also be set using the
touch buttons and above and below the touch
slider.
Cooktop power setting
When the power setting is activated, maximum cooking
zone power is available for a predefined time.
The available power is focused on the selected
cooking zone, meaning that the max. power of the
second cooking zone on that side is automatically and
temporarily reduced:
If the large cooking zone is operated using the
power setting, a maximum power level of 7 can be
selected in the small cooking zone.
If the small cooking zone is operated using the
power setting, a maximum power level of 8 can be
selected in the large cooking zone.
If the power level selected for the second cooking
zone is too high, P will blink three times and the
cooking zone will switch back to power level 9.
After 5 minutes, the cooking zone is automatically
switched back to power level
.
Noises
The following noises may occur in the cookware when
using induction cooking zones, depending on the material
and the finish of the base:
Humming may occur when using a high power level.
It decreases or disappears if the power level is
decreased.
Crackling or whistling may occur due to bases of
cookware made of different materials (e.g. sandwich
base).
Clicking sounds may occur during electronic switching
procedures, especially at low power levels.
Whirring may occur when the cooling fan is switched
on. In order to increase the service life of the
electronic system, the cooktop is equipped with a
cooling fan. The cooling fan switches on automatically
if the cooktop is used intensively. You will hear a
whirring sound. The cooling fan may continue running
after the device has been switched off.
5.5 Cooktop extractor functions
Cooktop extractor power adjustment
Die Regelung der Leistungsstufen erfolgt über das
Bedienfeld durch Berührungs- bzw. Bewegungsimpulse
auf dem Touch-Slider. Alternativ können die
Leistungsstufen auch über die Touch-Flächen und
ober- und unterhalb des Touch-Sliders eingestellt werden.
Extractor power setting
When the power setting is activated, maximum extractor
power is available for a predefined time.
This power setting makes it possible to suction away high
levels of cooking vapours more quickly.
Automatic extractor control
The extractor power level automatically adjusts itself
depending on the current cooktop settings. No manual
adjustment of the fan controls is necessary but it is
possible. The extractor power is automatically adjusted
to the highest power level used on all connected cooking
zones.
Function Power levels
Cooking level 1 2 3 4 5 6 7 8 9 P
Extractor power 4 4 4 4 5 6 7 8 9 P
Tab. 5.7 Extraction performance and cooking level
If the power level of a cooking zone is changed, the
extractor power is automatically adjusted after a 20
second delay.
Automatic after-run
The cooktop extractor continues to run at a lower level
and switches off automatically after a defined time.
