5 Device description
Observe all safety and warning information during
operation (see Safety chapter).
The appliance has the following features:
Cooktop:
Power setting
Automatic heat up function
Warming function
Cooking zone timers (automatic cut-off)
Short-time timer (egg timer)
Residual heat display
Pan size recognition
Childproofing feature
Safety shut-down
Cooktop extractor:
Touch-operated power control
Automatic extractor function
Automatic after-run
Safety shut-down
Filter service display
5.1 Model description
PURA:
BORA Pure induction glass ceramic cooktop with
integrated cooktop extractor – exhaust air
PURU:
BORA Pure induction glass ceramic cooktop with
integrated cooktop extractor – recirculation
5.2 Structure
2
1
4
5
3
6
Fig. 5.1 Cooktop
[1] Air inlet nozzle
[2] Stainless steel grease filter
[3] Cooktop
[4] Inlet opening
[5] Fan
[6] Operating panel
12
Fig. 5.2 Rear view PURA
[1] Exhaust opening
[2] Air guiding housing with housing base
