168 en | Appendix Control Panels
2018.07 | 10 | F.01U.303.996 Installation Manual Bosch Security Systems, Inc.
Switch 5 settings for line termination
If a D8125 POPEX module is connected, set switch 5 of only one D8128D to ON.
If a D8125 POPEX module is not connected, set switch 5 of all D8128Ds to OFF.
22.1.5 D8129 address settings
The D8129 connects to the control panel through a B600.
ZONEX 1 D8129 address switches ZONEX 2
Output
number
1 2 3 4 5 Output
number
1 to 8 OFF ON ON ON ON 65 to 72
9 to 16 ON OFF ON ON ON 73 to 80
17 to 24 OFF OFF ON ON ON 81 to 88
25 to 32 ON ON OFF ON ON 89 to 96
33 to 40 OFF ON OFF ON ON 97 to 104
41 to 48 ON OFF OFF ON ON 105 to 112
49 to 56 OFF OFF OFF ON ON 113 to 120
57 to 64 ON ON ON OFF ON 121 to 128
22.1.6 B901 address settings
Address Designation
0,0 Disabled
0,1 to 3,2 Doors 1 to 32 on SDI2 (SDIx in SDI2 mode),
Doors 1 to 8 for B8512
8,1 to 8,8 Doors 1 through 8 on SDIx bus in Legacy SDI
mode (D9210C with Fail Safe Unlock)
9,1 to 9,8 Doors 1 through 8 on SDIx bus in Legacy SDI
mode (D9210C with Fail Safe Lock)
22.1.7 B91x address settings
Address Switches
1 2 3 4 5 6
1 ON OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF
5 ON OFF ON OFF OFF OFF
6 OFF ON ON OFF OFF OFF
7 ON ON ON OFF OFF OFF
8 OFF OFF OFF ON OFF OFF
