Control Panels System overview | en 17
Bosch Security Systems, Inc. Installation Manual 2018.07 | 10 | F.01U.303.996
Features B9512G/
B9512G-E
B8512G/
B8512G-E
Number of plug-in cellular modules (B440/B441/B442/B443/B444) 1 1
Number of auxiliary power supply modules (B520) 8 4
Number of wireless receivers (B810/B820) 1 1
Number of cameras
3
16 8
1
The control panel supports 32 doors using the optional B901 Access Control Module. The control panel
supports up to 8 doors using the optional D9210C Access Control Interface Module.
2
The control panel supports up to 16 of the keypads as SDI keypads.
3
Bosch IP cameras use is supplementary in UL Listed systems.
3.3 Features
This section explains the control panel's notable features.
3.3.1 SDI2 interconnect wiring
The control panel and most compatible modules have interconnect wiring connectors. You can
use the connectors in place of terminal wiring. In installations with multiple SDI2 modules,
using interconnect wiring makes the installation quicker and easier than using terminal strip
wiring. You use any combination of terminal and interconnect wiring to wire multiple modules
in parallel, but do not wire a single module to the control panel using both terminal and
interconnect wiring.
The interconnect wiring connectors are "keyed" (interconnect wiring plug can fit in only one
direction).
Each SDI2 module that has an SDI2 interconnect wiring connector comes with a 12 in (30 cm)
interconnect cable.
3.3.2 Points
The control panels provide up to the following number of points of protection:
– B9512G. 599
– B8512G. 99
Point programming parameters determine the control panel’s response to open and shorted
conditions on the sensor loop for the point. Several options allow individual point
programming to custom-fit the protection to the installation.
The control panel has eight on-board points, points 1 to 8.
The SDI2 bus allows for point expansion with:
– One or more B208.
– One or more B299.
– A B810 wireless receiver or B820 SDI2 Inovonics Interface Module.
The B600 Retrofit (ZONEX) module allows for connection to a D8125 (D8125MUX, D8125INV)
module for point expansion.
3.3.3 Areas and accounts
The control panels provide up to the following number of areas:
– B9512G. 32
– B8512G. 8
You can assign all points to a single area or distribute them over multiple areas.
Users can turn areas on and off individually or together. You can assign an authority level to a
user that allows the user to turn an area on from a remote keypad in another area.
