170 en | Appendix Control Panels
2018.07 | 10 | F.01U.303.996 Installation Manual Bosch Security Systems, Inc.
Fail mode Central station
Modem4
SDI address setting Keypad display
UNLOCKED SDI #38 86 Door #6
UNLOCKED SDI #39 87 Door #7
UNLOCKED SDI #40 88 Door #8
LOCKED SDI #33 91 Door #1
LOCKED SDI #34 92 Door #2
LOCKED SDI #35 93 Door #3
LOCKED SDI #36 94 Door #4
LOCKED SDI #37 95 Door #5
LOCKED SDI #38 96 Door #6
LOCKED SDI #39 97 Door #7
LOCKED SDI #40 98 Door #8
22.1.9 SDI keypad address settings
D1255VFD Keypad / D125xRB Fire Keypad / D126x LCD Keypad address switch settings.
Notice!
D126x keypads only use addresses 1-8. To access the switch settings, press and hold [0] until
the menu changes.
Address Switches
1 2 3 4 5 6
1 ON ON ON ON Encoding
Tone ON/
OFF
ON
2 OFF ON ON ON ON
3 ON OFF ON ON ON
4 OFF OFF ON ON ON
5 ON ON OFF ON ON
6 OFF ON OFF ON ON
7 ON OFF OFF ON ON
8 OFF OFF OFF ON ON
9 ON ON ON OFF ON
10 OFF ON ON OFF ON
11 ON OFF ON OFF ON
12 OFF OFF ON OFF ON
13 ON ON OFF OFF ON
14 OFF ON OFF OFF ON
To Next Page
