7.3.4 Multiple measurements
Sensor Measuring range Resolution Tolerance
Lambda sensor voltage 0.000V ... 5.000V 10 mV 1% from measured value
+ 2 mV
7.3.5 Ignition point/timing
Sensor Measuring range Resolution Tolerance
OT/reference-mark sensor -179 ... 180 °crankshaft 0.1 °crankshaft
+ 0.8 °crankshaft + 1 dig.
to Term.1 or clip-on trigger 0.0 ... 60 °crankshaft
sensor, stroboscope to term.1 100 ... 8000 rpm 0.1 °crankshaft
+ 0.5 °crankshaft + 1 dig.
at or clip-on trigger sensor
7.3.6 Dwell angle
Sensor Measuring range Resolution Tolerance
Terminal 1 0 ... 100 % 0.1 %
+ 1 %
0 ... 360 °advance angle 0.1 °
+ 0.5 °
0.0 ... 50.0 ms 0.01 ms
+ 0.3 % from meas. value + 1 dig.
50.0 ... 99.9 ms 0.1 ms
+ 0.3 % from meas. value + 1 dig.
7.3.7 Start of delivery/Injection timing
Sensor Measuring range Resolution Tolerance
Clamp-on pickup to -179 ... 180 °KW 0.1 °crankshaft + 1 °crankshaft + 1 dig.
OT or stroboscope
