Bosch BEA 350 - Reference Numbers When Downloading DTM Firmware

60
No. Message Remedy Section
4058 Faulty calibration of O
2
sensor Repeat O
2
calibration 4.7.4
Replace O
2
sensor 10.11
4059 A/D converter off-scale Replace measuring bank 10.10
4061 CRC checksum error Perform download for exhaust-gas analyzer module 9.9
Replace measuring bank 10.10
4062 Exhaust-gas analyzer module has received Reboot BEA, if error still present:
unknown command Install BEA system software 5.23
4063 Channel not ready for measurement Replace measuring bank 10.10
4066 Calibration of NO channel outside tolerance Calibrate NO channel 4.12.5
Check internal hosing as per gas circuit diagram 12.5
Replace NO sensor 10.20
4067 Recalibrate with calibrating gas Calibrate NO channel 4.12.5
4068 Valve test after leak test not OK Replace valve 10.19
4090 Unknown error Replace measuring bank 10.10
4091 Parameter error when function called Perform download for exhaust-gas analyzer module 9.9
Replace measuring bank 10.10
4099 Exhaust-gas analyzer module does Check voltage supply 10.2 and 10.3
not respond Check connection cable 12.1
Replace measuring bank 10.10
8.10 Reference numbers when downloading DTM firmware
No. Designation Remedy Chapter
5000 Wrong number of arguments Check AMM connecting cable to DTM using ohmmeter.
5001 Unknown interface Replace LP control computer 10.27
5033 Cannot open interface Replace DTM-LP 10.28
5034 Cannot load data module
5036 Chip ID timeout Connecting cable not plugged in or faulty
Check connecting cable using ohmmeter 12.4
5037 Chip ID faulty
5038 Boot2 Echo Compare error
5039 Boot2 Echo Timeout error Replace DTM-LP 10.28
5040 Protocol STX Timeout
5041 Protocol DLE Timeout
5042 Init. message from C167 missing or faulty
