8.13 Malfunction messages for testing OBD printed circuit board with KTS115PC program
i Multiple errors may be reported simultaneously, e.g. = $0001 + $ 0002 + $ 0004
8.13.1 Error messages for "SDTEST"
No. Possible cause Remedy Chapter
$0001 OBD/CAN-LP defective OBD/CAN-LP replace 10.30
$0002
$0004 OBD/CAN connection cable Repeat test using short circuit plug KS 350.
or OBD/CAN-LP defective. If malfunction no longer present, OBD/CAN-
connecting cable should be replaced.
If malfunction continues then OBD/CAN-LP
to be replaced. 10.30
$0008 No power supply. Banana plugs B+ (red) and GND (black) of OBD/CAN-
or OBD/CAN-LP defective. Connect adapter line connecting cable AL 350 to voltage
supply.
Repeat test using AL 350.
If error message still
present, repeat test using short circuit plug KS 35.
If malfunction no longer present, OBD/CAN-
connecting cable should be replaced.
If malfunction still present, OBD/CAN-LP
to be replaced. 10.30
$0016
$0032
$0064 OBD/CAN connection cable Repeat test using short circuit plug KS 350.
$0128 or OBD/CAN-LP defective. If malfunction no longer present, OBD/CAN-
$0256 connecting cable should be replaced.
$0512 If malfunction still present, OBD/CAN-LP
8.13.2 Error messages for "DLCTEST"
No. Possible cause Remedy Chapter
$0001 OBD/CAN-LP defective OBD/CAN-LP to be replaced. 10.30
$0002
$0003 B+ not connected, or Banana plugs B+ (red) and GND (black) of
the adapter cable
$0016 OBD/CAN-LP defective Connect AL 350 to power supply.
Repeat test.
If malfunction still present, repeat test
using short circuit plug KS 350.
If malfunction no longer present, OBD/CAN-
connecting cable should be replaced.
If malfunction still present, OBD/CAN-LP to be replaced. 10.30
$0004-
§0015 OBD/CAN-LP defective OBD/CAN-LP to be replaced. 10.30
