Bosch BEA 350 - View of Equipment Side of Control Module PCB

71
10.4 View of equipment side of control module PCB
X2
1 1 = +12V
2 2 = + 8V
3 3 = + 5V
4 4 = GND
5 5 = - 5V
6 6 = - 12V
P2 = ⊥
P1 = ⊥
P3 = ⊥
LP-223
X26
X24
1
2
3
1
2
3
X25
1
2
3
4
X22
1
2
3
X5
1
2
15
9
Seriell - AMM
U
AMM
U P
U V
U PUMP
Lithium
Battery
3,0 V
FD
HD
LP -
DTM
LP - OBD
X6
1
2
15
9
1
2
20
19
X8
X19
1
2
3
X20
1
2
X21
1
2
3
4
⊥
+12V
⊥
+12V
⊥
+5V
⊥
9-16V
Printer
⊥
9-16V
+12V
U
HD
⊥
⊥
+12V
+5V
U
FD
⊥
+5V
TFT-
Display
U TFT =
B 1KV
Keyboard
1
2
3
IR
⊥
+5V
X17
X4
X13
X12
