8.3 Assignment of the CCU to a vehicle by the
service provider
i The CCU-Modul must be assigned to a vehicle by the
repair shop carrying out the installation. The internet
address can be obtained from your service provider.
! Always make sure the assignment of the vehicle to the
CCU-Modul is correct.
! Once the CCU-Modul has been assigned to a vehicle, this
CCU-Modul may be installed in this vehicle only.
9. Technical Data
9.1 CCU-Modul
Property Value / range
Dimensions H x W x D 27 x 127 x 65 mm
Temperature:
Storage and transportation
-40 °C – 85 °C
-40 °F – 185 °F
Temperature:
Function
-20 °C – 60 °C
-4 °F – 140 °F
Quiescent current < 1,0 mA
Operating voltage 9 - 16 V (DC)
Operating current, peak at 14.4V 260 mA
Weight 128 g
9.2 Two-wire connection cable
(special accessory)
Property Value / range
Temperature:
Operation, storage and transportation
-40 °C – 85 °C
-40 °F – 185 °F
Operating voltage 32V
Fuse to SAE J2077 / ISO 8820-3 2A, ATM / MINI
9.3 RED (Radio Equipment Directive)
Wireless link Frequency band Maximum radiated transmitter
power output
GSM 800 / 900 MHz 33 dBm
GSM 1800 / 1900 MHz 24 dBm
