Creating a new conditional function
Follow the steps shown in the screenshot.
1st: Double-click on
'Math Channels'
in Project Tree
2nd: Click on
the dropdown
arrow beside
''Add channel'
3rd: Choose
'Conditional
Function'
The ‘Create/edit conditional function’ window appears. Define the conditional
function using the following configuration possibilities:
a)
b)
c)
d)
e)
a) Enter the name of the conditional function.
b) Enter the If-condition. Click on the pencil symbol to open an editor to enter expressions.
c) Enter the Then-condition. Click on the pencil symbol to open an editor to enter expressions.
d) Enter the Otherwise-condition.Click on the pencil symbol to open an editor to enter expressions.
e) Enter the reset value (must be a number).
Click ‘Finish’ when done.
8.6.2
