Bosch DIVAR AN 5000 User Manual

Id
Name Function
1 Menu bar Here you have the following options:
Play Window (default window) activates a window where you can
play pre-recorded files.
Export File activates a window where you can choose files to
export to a pre-defined directory – see Export file, page 125
Authentication activates a window where you can check the
validity of a recording – see Authentication (checking watermark),
page 124
Config is used to setup how the player saves and formats
snapshots, and the language for the user interface – see
Configuration, page 126
2
Activates a directory overview where you can browse and choose
a file to play. Double-click on a specific file to start playing.
3 Click to show player in full screen (press Esc to return to
standard screen)
DIVAR AN 3000 / DIVAR AN 5000 Archive Player operation | en 121
Bosch Security Systems Operations Manual 2014.10 | 2.0 | AM18-Q0669

Bosch DIVAR AN 5000 Specifications

General

Motion sensor	Yes
Total storage capacity	2000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Compatible operating systems	Windows XP, Windows Vista, Windows 7.
Playback resolutions supported	960x576, 960x480, 704x576, 704x480, 704x288, 704x240, 352x288, 352x240, 176x144, 176x120
Audio input	4
BNC input ports	16
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	3000 GB
Power requirements	100-240VAC 50-60Hz
Optical drive included	No
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 93 %

Weight and Dimensions

Dimensions (WxDxH)	440 x 420 x 70 mm
