Quick menu
When in live viewing mode, right-click the mouse for the following quick menu:
Figure 7.4: Quick menu
Here you can select:
– View 1, 4, 9, 16 – choose here the number of view windows shown on Monitor A (one-
window, four-windows, nine-windows or sixteen-windows). Press play to activate the new
view.
– Pan/Tilt/Zoom – only possible if you have a PTZ camera attached and configured
– Color setting – to change the color settings of the viewed camera images – see below
– Search/Play –searching for records, and playing/exporting them – see Search/Play, page
97
– Sequence on – activate a camera tour sequence on Monitor A (to disable the sequence,
access Quick Menu again and select ‘Sequence off’)
– Alarm output – access the alarm output screen to configure the alarm output relays – see
Alarm Output, page 72
– Switch user –activate the Login screen where you can login as a different user
– Main menu – for settings and user modes – see Main menu, page 91
Notice!
Pan/Tilt/Zoom and color settings in multi-window mode
The Pan/Tilt/Zoom and Color setting applies for the currently selected channel. If you are in
multiple-window mode, the system automatically switches to the corresponding channel.
7.1.4
90 en | Operating instructions DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems
