Bosch DIVAR AN 5000 - Page 151

Playback 960H: 960x576 (PAL), 960x480 (NTSC)
4CIF: 704x576 (PAL), 704x480 (NTSC)
2CIF: 704x288 (PAL), 704x240 (NTSC)
CIF: 352x288 (PAL), 352x240 (NTSC)
QCIF: 176x144 (PAL), 176x120 (NTSC)
Compression H.264
Inputs 4, 8 or 16 composite video 1 Vpp, 75 ohm, CVBS (BNC)
Outputs 1 channel Mon. A: CVBS (BNC)
1 channel Mon. A: HDMI
1 channel Mon. A: VGA
1 channel Mon. B: CVBS (BNC)
Support for simultaneous CVBS/VGA/HDMI output to Mon.
A
Monitors
MON.A Live, playback, menus
VGA: analog RGB max. 1920x1080, 60 Hz
HDMI: digital RGB max. 1920x1080, 165 MHz
CVBS: 1 Vpp, 75 ohm, BNC (NTSC/PAL)
Resolution (MON.A) CVBS (PAL): 704x576
CVBS (NTSC): 704x480
VGA: 1920x1080, 1280x1024, 1280x720, 1024x768
HDMI: 1920x1080, 1280x1024, 1280x720, 1024x768
960H camera: 960x576 (PAL), 960x480 (NTSC)
720H camera: 704x576 (PAL), 704x480 (NTSC)
MON.B Live
CVBS: 1 Vpp, 75 ohm, BNC
Resolution (MON.B) CVBS (PAL): 704x576
CVBS (NTSC): 704x480
Audio
Inputs 4-ch RCA (for 4/8/16 channel), 200 to 3000 mV,
10 kOhm (RCA)
Output Mono RCA, 200 to 3000 mV, 5 kOhm (RCA)
MIC input Mono talk input RCA, 200 to 3000 mV, 10 kOhm (RCA)
Compression G.711A
Sample rate 8 kHz per channel
Bit rate 8-bit
DIVAR AN 3000 / DIVAR AN 5000
Technical specifications | en 151
Bosch Security Systems Operations Manual 2014.10 | 2.0 | AM18-Q0669
