When selecting camera channels (on the DIVAR AN 3000 ),
press first the Shift button and then the required channel
number – see the keys below with number functions
Up / Down
In menu mode, move up and down through menu items or
values
Increase/decrease numeral in a numeric field
In PTZ mode, use to control the tilt functions of the selected
camera
In text mode or when choosing a camera channel, input
number 3 or 9 (only on DIVAR AN 3000 )
Left Right
In menu mode, move around through menu items or values
In PTZ mode, use to control the pan function of the selected
camera
In playback, click to control playback bar
In text mode or when choosing a camera channel, input
number 6 or 7 (only on DIVAR AN 3000 )
ESC ESC Go to previous menu, or cancel current operation
In playback, click to restore real-time monitor mode
Enter Select a submenu or menu item, or confirm selections made in
menus
Go to default button
Go to Quick menu
Window switch Mult Click to switch between one-window and multiple-window (2,
4, 9, and 16)
Assistant Fn In one-window monitor mode, click to display assistant
function: PTZ control and image color
In motion detection setup, use the Fn and direction keys for
setup
In text mode, click to switch between numeral, English
character (small/capitalized), etc.
Press for 1.5 seconds to delete the previous character before
the cursor
Realize other special functions
Slow forward Multiple slow play speeds or normal playback
In text mode or when choosing a camera channel, input
number 5 (only on DIVAR AN 3000 )
Fast play Various fast speeds and normal playback
In text mode or when choosing a camera channel, input
number 4 (only on DIVAR AN 3000 )
86 en | Operating instructions DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems
