– Sequence
Access to these functions requires the correct user level. Check with your administrator if you
do not have access.
For more information:
– Playback and zoom – see below
– see PTZ, page 95
– see Sequence, page 95
Playback and Zoom
Move the mouse to the top centre of the video of the current channel; the system pops up the
following playback and zoom control bar.
Figure 7.8: Playback and zoom
If your mouse stays inactive in this area for more than 6 seconds, the control bar automatically
disappears. See the following table for detailed information on the buttons on this control bar.
Icon name Function
Instant playback Press to playback the previous 5-60 minutes recorded on the
current channel (default is 5 minutes). The playback screen
supports drag and play function - use your mouse to drag the
play bar to any playback start time (use the pause and exit
functions as required). During the instant playback:
– you can not see the channel title and record status of
current channel (they only reappear once you exit preview
playback)
– you can not switch the displayed channel or change current
window-display mode
Set the time for Instant playback in Main Menu > Setting >
General.
Note: The system may pop up a dialog box if there is no
recorded data for the current channel, or you need to accept a
disclaimer before playing.
Digital zoom
Zoom in on a specified zone of current channel (zoom-in
function is supported in multiple-channel view).
When you click on the zoom icon it will change to a new icon
; you can now select an area by holding down the left
mouse button and dragging an area on the screen. Release the
mouse and the selected area will be zoomed.
Right-click the mouse to exit the zoomed area.
Exit the digital zoom function at any time by clicking on the icon
again – it will change back to
.
94 en | Operating instructions DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems
