Bosch DIVAR AN 5000 User Manual

4 Calendar
and time
Select a date to overview the recordings available for that day (dates
highlighted in blue have recordings available for that day). The time bar on
the bottom of the screen will show a 24-hour trace of the recordings
available for the chosen date.
If required, play a recording for a particular date as follows:
– Assign a start time (hour, minute, second) in the time field (below the
calendar)
– Press the play button
– Click on a colored zone on the time bar (at the bottom of the screen)
to start playing at that selected time
5
Play or Pause (the ‘pause’ button is displayed if the DVR is already playing
and you wish to pause the play)
Stop playback
Backward play
In normal play mode, left click the button, the file begins backward play.
Click it again to pause current play.
In backward play mode, click to restore normal play.
In playback mode, click to play the next or the previous section (click
continuously to watch consecutive files from the same channel.
In normal play mode, press pause then click and to begin frame-by-
frame playback.
In frame-by-frame playback mode, click
to restore normal playback.
Slow play
In playback mode, click for various slow play modes such as slow play 1,
slow play 2, etc.
Fast forward
In playback mode, click to realize various fast play modes such as fast
play 1, fast play 2, etc.
Smart search – see description below
Turn the audio on/off and adjust the volume during video playback
Click in full-screen mode to export snapshot(s) to a memory device (scroll
to the bottom of the full-screen to enable the snapshot button). Use the
Export screen to setup the snapshot export settings - see Export, page 103.
Digital
zoom
When the system is in playback mode:
1. Left-click the mouse in the screen and hold down the mouse button.
2. Drag to select a section then release the mouse button.
3. Left-click in the selection for digital zoom of the selection.
4. Right-click to exit zoom.
98 en | Operating instructions DIVAR AN 3000 / DIVAR AN 5000
2014.10 | 2.0 | AM18-Q0669 Operations Manual Bosch Security Systems

Bosch DIVAR AN 5000 Specifications

General

Motion sensor	Yes
Total storage capacity	2000 GB
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Compatible operating systems	Windows XP, Windows Vista, Windows 7.
Playback resolutions supported	960x576, 960x480, 704x576, 704x480, 704x288, 704x240, 352x288, 352x240, 176x144, 176x120
Audio input	4
BNC input ports	16
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	3000 GB
Power requirements	100-240VAC 50-60Hz
Optical drive included	No
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 93 %

Weight and Dimensions

Dimensions (WxDxH)	440 x 420 x 70 mm
