1 689 989 158 2012-10-12| Robert Bosch GmbH
1 687 023 652 – 658 | 21 | 21 en
6. Maintenance
! Work on electrical equipment is only to be per-
formed by persons with sufficient knowledge and
experience of electrical systems.
6.1 Cleaning
! Do not use abrasive cleaning agents and coarse
workshop cloths.
¶ The housing is only to be cleaned with a soft cloth
and neutral cleaning agents.
6.2 Maintenance
i The PC does not require any special maintenance
work. Keep the PC clean.
6.3 Spare and wearing parts
! The PC should never be opened by the user. Inform
Customer Service in the event of persistent prob-
lems. Spare parts are available for replacement
by Customer Service. The entire PC can also be
replaced – the order numbers for replacement and
exchange PCs are listed below.
Series Spare part Exchange part
1 687 023 652
1 687 023 658 1 682 666 373
1 687 023 653
1 687 023 654 1 687 023 657 1 682 666 371
1 687 023 655 1 687 023 655 1 682 666 372
7. Technical data
7.1 Dimensions and weights
Feature Value/Range
Dimensions (H x W x D) Tower 360 x 185 x 395 mm
14.17 x 7.28 x 15.55 inch
Dimensions (H x W x D) Desktop 150 x 425 x 425 mm
5.91 x 16.73 x 16.73 inch
Weight 8 kg
17.64 lb
7.2 Temperature and humidity
Feature Value/Range
Storage temperature -25 °C – 60 °C
-13 °F – 140 °F
Operating temperature 5 °C – 40 °C
41 °F – 104 °F
Relative humidity in operation 80 % (36 °C)
80 % (96.8 °F)
7.3 Specifications
Feature Value/Range
Input frequency 50 — 60 Hz
Input voltage 115/240 V AC +/- 10 %
