Bosch OBD 1350 - KOEO On Demand; KOEO Injector Buzz

580001 | REV. A | 11.2016
OBD 1350 ProGrade OBDII Scan Tool
|
User guide | 43
|
en
On Demand Tests
Acronyms
KOEO Output State
KOER On Demand
Component Locator
System Setup
Review Data
Print Data
Code Lookup
KOEO On Demand
2. Perform the following:
• Set parking brake.
• Transmission in park (P) or neutral (N).
• Turn A/C off.
• Start engine and let idle until hot.
• Turn ignition key off.
• Wait 10 seconds. Turn key on engine off. Do not
start engine.
• For the 7.3L Powerstroke diesel, depress/hold
throttle during test.
For Gasoline engines, do not touch the throttle during
test.
3. Press to begin the test. The time remaining is
displayed.
KOEO On Demand
Please Wait
Test is running.
Time remaining
2:59
The following system components are tested:
– Electric radiator cooling fan - Avoid cooling fan!
– Fuel pump
– Check engine light
– Idle speed control solenoid
If no DTCs are present, a message stating “No Codes
Found” is displayed.
Read KOEO Codes
Press ENTER to continue
No codes found
4. View and write down DTCs.
• Use the UP and DOWN keys.
Intake Air Temperature Sensor
1 Circuit High Input
1/1
ECM $10
P0113
Erase FFrameRead
FORD KOEO CODES
5. Return to the On Demand Tests Menu.
• Press .
5.20 KOEO Injector Buzz
This test is available on some Ford trucks equipped with
a diesel engine. The KOEO Injector Buzz is a functional
test performed on demand with the ignition key on and
engine off. The test determines if the injector circuits
and solenoids are operating correctly and without faults.
All injectors are buzzed initially (audible feedback of
solenoids energizing the valves) for approximately 2
seconds. Then each injector buzzes individually for
approximately 1 second, in numerical order (1 – 8).
From the On Demand Tests Menu:
1. Select KOEO Injector Buzz.
• Use the UP and DOWN keys until KOEO
Injector Buzz is highlighted.
• Press .
On Demand Tests
KOER Glow Plug
KOEO On Demand
KOEO Output State
KOER On Demand
Review Data
KOER Cylinder Contribution
Component Locator
Acronyms
KOEO Injector Buzz
2. Perform the following:
• Set parking brake.
• Transmission In park (P) or neutral (N).
• Turn A/C off.
• Start engine and let idle until hot.
• Turn ignition key off.
• Wait 10 seconds. Turn key on engine off. Do not
start.
3. Start test.
• Press .
Listen for one long buzz and then 8 short equal buzzes
as each fuel injector is energized.
