PID PID Description
ABS FRP Absolute Fuel Rail Pressure
ABS LOAD Absolute Load Value
ABS TPS B, C Throttle Position B, C
ABSLT TPS Absolute Throttle Position
ACC POS D Accelerator Pedal D, E, F
ACC POS REL Relative Accelerator Pedal Position
AECD1_TIME1,
TIME 2
Total Run Time with EI-AECD #1 Timer
1 Active, #2 Timer Active
AECD10_TIME1,
TIME 2
Total Run Time with EI-AECD #10
Timer 1 Active, #2 Timer Active
AECD11_TIME1,
TIME 2
Total Run Time with EI-AECD #11
Timer 1 active, #2 Timer Active
AECD12_TIME1,
TIME 2
Total Run Time with EI-AECD #12
Timer 1 active, #2 Timer Active
AECD13_TIME1,
TIME 2
Total Run Time with EI-AECD #13
Timer 1 active, #2 Timer Active
AECD14_TIME1,
TIME 2
Total Run Time with EI-AECD #14
Timer 1 active, #2 Timer Active
AECD15_TIME1,
TIME 2
Total Run Time with EI-AECD #15
Timer 1 active, #2 Timer Active
AECD16_TIME1,
TIME 2
Total Run Time with EI-AECD #16
Timer 1 active, #2 Timer Active
AECD17_TIME1,
TIME 2
Total Run Time with EI-AECD #17
Timer 1 active, #2 Timer Active
AECD18_TIME1,
TIME 2
Total Run Time with EI-AECD #18
Timer 1 active, #2 Timer Active
AECD19_TIME1,
TIME 2
Total Run Time with EI-AECD #19
Timer 1 active, #2 Timer Active
AECD2_TIME1,
TIME 2
Total Run Time with EI-AECD #2 Timer
1 Active, #2 Timer Active
AECD20_TIME1,
TIME 2
Total Run Time with EI-AECD #20
Timer 1 active, #2 Timer Active
AECD3_TIME1,
TIME 2
Total Run Time with EI-AECD #3 Timer
1 Active, #2 Timer Active
AECD4_TIME1,
TIME 2
Total Run Time with EI-AECD #4 Timer
1 Active, #2 Timer Active
AECD5_TIME1,
TIME 2
Total Run Time with EI-AECD #5 Timer
1 Active, #2 Timer Active
AECD6_TIME1,
TIME 2
Total Run Time with EI-AECD #6 Timer
1 Active, #2 Timer Active
AECD7_TIME1,
TIME 2
Total Run Time with EI-AECD #7 Timer
1 Active, #2 Timer Active
AECD8_TIME1,
TIME 2
Total Run Time with EI-AECD #8 Timer
1 Active, #2 Timer Active
AECD9_TIME1,
TIME 2
Total Run Time with EI-AECD #9 Timer
1 Active, #2 Timer Active
ALCOHOL Alcohol Fuel Percent
BARO PRS Barometric Pressure
BAT_PWR Hybrid Battery Pack Remaining Life
BP_A_ACT, B_
ACT
Boost Pressure Sensor A, Sensor B
BP_A_CMD, B_
CMD
Commanded Boost Pressure A, Pres-
sure B
BP_A_STAT, B_
STAT
Boost Pressure A Control Status, B
Control Status
CACT 11, 12
Charge Air Cooler Temperature Bank
1 Sensor 1 supported, Sensor 2
supported
PID PID Description
CACT 21,22
Charge Air Cooler Temperature Bank
2 Sensor 1 supported, Sensor 2
supported
CALC LOAD Calculated Engine Load
CAT TEMP11,
TEMP12
Cataltic Converter Temp Bank1, Temp
Bank 3
CAT TEMP21,
TEMP22
Cataltic Converter Temp Bank2, Temp
Bank 4
CLR DIST Distance since erase
CLR TIME Minutes Run since Erase
CLR TRPS Warmups Since Erase
CMD EQ RAT Commanded Equivalence Ratio
COOLANT Engine Coolant Temp
DPF_REG_AVGD Average Distance Between DPF Regen
DPF_REG_AVGT Average Time Between DPF Regen
DPF_REG_STAT
Diesel Particulate Filter (DPF) Regen
Status
DPF_REG_TYP
Diesel Particulate Filter (DPF) Regen
Type
DPF_REGEN_
PCT
Normalized Trigger for DPF Regen
DPF1_DP,
DPF2_DP
Diesel Particulate Filter (DPF) Bank 1
Delta Pressure Bank 2 Delta Pressure
DPF1_INP,
DPF2_INP
Diesel Particulate Filter (DPF) Bank 1
Inlet Pressure, Bank 2 Inlet Pressure
DPF1_INT,
DPF2_INT
DPF Bank 1 Inlet Temperature Sensor,
Bank 2 Inlet Temperature Sensor
DPF1_OUTP,
DPF2_OUTP
Diesel Particulate Filter (DPF) Bank
1 Outlet Pressure, Bank 2 Outlet
Pressure
DPF1_OUTT,
DPF2_OUTT
DPF Bank 1 Outlet Temperature Sen-
sor, Bank 2 Outlet Temperature Sensor
ECT 1, 2
Engine Coolant Temperature 1, Tem-
perature 2
EGR CMD Comanded EGR
EGR ERR Exhaust Gas Recirculation Error
EGR_A_ACT, B_
ACT
Actual EGR A Duty Cycle / Position, B
Duty Cycle / Position
EGR_A_CMD, B_
CMD
Commanded EGR A Duty Cycle / Posi-
tion, B Duty Cycle / Position
EGR_A_ERR, B_
ERR
EGR A Error, B Error
EGRT 11, 21
Exhaust Gas Recirculation Tempera-
ture Bank 1 Sensor 1, Bank 2 Sensor 1
EGRT 12, 22
Exhaust Gas Recirculation Tempera-
ture Bank 1 Sensor 2, Bank 2 Sensor 2
EGT 11, 21
Exhaust Gas Temperature (EGT) Bank
1 Sensor 1, Bank 2 Sensor 1
EGT 12, 22
Exhaust Gas Temperature (EGT) Bank
1 Sensor 2, Bank 2 Sensor 2
EGT 13, 23
Exhaust Gas Temperature (EGT) Bank
1 Sensor 3, Bank 2 Sensor 3
EGT 14, 24
Exhaust Gas Temperature (EGT) Bank
1 Sensor 4, Bank 2 Sensor 4
EMIS_SUP
Emission requirements to which vehi-
cle is designed
ENG RUN Time Since Engine Start
ENG SPEED Engine RPM
EOT Engine Oil Temperature
