● IRQ (Interrupt) conflict with other PC hardware components of the control
cabinet PC
● The software of the card was not installed
10.1.6 BIOS settings
No further settings have to be made in the BIOS setup. The corresponding
settings have already been set for the normal operation.
10.2 Housing dimensions
The control cabinet PC can be mounted using mounting holes. For the
corresponding dimensions, please refer to the following figures:
Fix the devices with M5 screws.
Bosch Rexroth AG
Mounting, demounting and electric installation
IndraControl VPB 40.4
26/87
DOK-MLC***-INDRACTRLV4-IT02-EN-P
