12.9.1 Context menu
Right-click on the icon of the application to display the context menu. Items in
the menu are displayed depending on the status “active” (black) or “inactive”
(grey).
Menu Subfunction Description
System firmware Yes Active if the MLC system firmware is loaded
Initial firmware Yes Active if the initial firmware is loaded
Diagnostics and settings No Operating elements and status information (LED display
and message text)
Activate boot stop No Set the control to the "BOOTSTOP" mode. Use the
"Diagnostics and settings" dialog to display and enable
the boot stop functions.
For a description of the individual "BOOTSTOP"
functions, refer to the chapter "Menu "BOOTSTOP"" in
the documentation "IndraLogic XLC IndraMotion MLC
14VRS Functional Description" (see chapter 1.4
"Related documents" on page 2) or to the IndraWorks
online help
About… No Displays general application information
Tab. 12-3: Main menu
Menu Subfunction Description
Reboot No Reboot of the system firmware
IndraMotion Service Tool No Open an external browser and transfer the "IndraMotion
Service Tool" web interface address
Activate initial firmware No Initial firmware is enabled
Tab. 12-4: "System firmware" menu
Menu Subfunction Description
First Touch web
interface…
No Open an external browser and transfer the "First Touch"
web interface address
Windows Event Viewer… No Start the external application "Windows Event Display"
Activate system firmware No System firmware is enabled
Tab. 12-5: "Initial firmware"
12.9.2 Status display
The states of the control and the application are displayed as icon in the
Windows System Tray. This display is supplemented by the respective
information as tooltip.
Bosch Rexroth AG
Device description
IndraControl VPB 40.4
58/87
DOK-MLC***-INDRACTRLV4-IT02-EN-P
