Wraptor A6200 User Manual 1
1 Introduction
The Wraptor™ A6200 Wrap Printer Applicator prints and wraps labels on wires and cables from 0.06
to 0.25 inches in diameter, including any casing around the wire or cable. Design labels on your
computer using Brady Workstation software. Transfer the labels to the printer for printing and
wrapping.
System Specifications
The Wraptor A6200 printer has the following specifications:
• 300 dots per inch (11.8 dots per mm) print resolution
• 1.5 inches per second (38.1 mm per second) print speed
• Wrap speed 7 seconds or less to print and apply)
• Accommodates wires between 0.06” (1.524 mm) and 0.25” (6.35 mm) in diameter
• Supports label widths of 1" (25.4 mm) or 0.5" (12.7 mm)
• Supports labels from 0.75” (19.05 mm) to 1.25” (31.75 mm) high
(1.25” maximum printable height)
• One-year warranty
• Accepts USB drives for added storage capability and standalone operation. USB drives must be
formatted with FAT, FAT32, or exFAT file systems. The
Wraptor A6200
printer does not support
NTFS.
Physical Dimensions
Physical U.S. Units Metric Units
Dimensions with touch screen
folded flat (width, height, depth)
8.8 x 8.3 x 11.7 in 22.4 x 21.1 x 29.7 cm
Weight 8.7 lbs 3.9 kg
