System Overview
1
Infusomat® Space 6.0 1 - 7EN
4. Turn the emergency release plug carefully with the emergen-
cy release crank through 90° to the
right (clockwise in arrow
direction) until stop and remove the plug out of the housing.
5. Insert the emergency release crank in the housing opening.
The crank must be pushed in the hexagon so
cket of the lock
bolt drive.
CAUTION
Do not turn the emergency release crank past the stop as this may
damage the housing.
6. Turn the emergency release crank to the right (clockwise ac-
cording to arrow direction) until the operating unit is re-
leased and opens.
Fig.: 1 - 5
Fig.: 1 - 6
