FT800 Series Programmer Guide
Version 2.1
Document Reference No.: BRT_000030 Clearance No.: BRT#037
39
Product Page
Document Feedback Copyright © Bridgetek Limited
Register Definition 11 REG_VOFFSET Definition
31 9 0
Note:
REG_VOFFSET Definition
Bit0 - 9: The value of these bits specifies how many lines takes after the start of new frame.
R/W
Address: 0x102440
Reset Value: 0x00C
Reserved
Register Definition 12 REG_VCYCLE Definition
31 10 9 0
Note:
REG_VCYCLE Definition
Bit0 - 9: The value of these bits specifies how many lines in one frame.
R/W
Address: 0x10243C
Reset Value: 0x124
Reserved
