Register Definition 15 REG_HSIZE Definition
Please reference to section 2.2.1
31 10 9 0
Address: 0x102430
Reset Value: 0x1E0
Note: NONE
Bit0 - 9: These bits are used to specify the numbers of PCLK cycles per horizonal line.
R/W
Reserved
REG_HSIZE Definition
Register Definition 16 REG_HOFFSET Definition
Please reference to section 2.2.1
31 10 9 0
Address: 0x10242C Reset Value: 0x2B
Note: NONE
Bit0 - 9: These bits are used to specify the numbers of PCLK cycles before pixels are scanned
out.
R/W
Reserved
REG_HOFFSET Definition
