9 - TROUBLESHOOTING
9-1
Check all wire connections before replacing any part.
ELECTRICAL TIPS
COMPLAINT CAUSE REMEDY
POWER ON light not
illuminated
1. Hi-limit tripped
2. Faulty light
3. Faulty cook/filter switch
4. Faulty Fuse
1. Reset or replace
2. Replace
3. Replace
4. Replace
Timer will not time
1. Controller in program mode
2. Pressure regulating valve
OPEN
3. Microswitch faulty or out of
adjustment
1. Exit program mode
2. CLOSE
3. Replace or adjust
HEAT ON light not
illuminated
1. Controller in program mode
2. Faulty light or controller
3. Faulty temperature control
1. Exit program mode
2. Replace controller
3. Replace
Hi-limit will not reset
1. Cooking oil temperature
too high
2. Faulty hi-limit
1. Allow oil to cool approxi-
mately 100°F
2. Replace
Heating element(s) won’t heat
1. Controller in program mode
2. Faulty element(s)
3. Faulty contactor
1. Exit program mode
2. Replace
3. Replace
Cooking oil temperature too
hot or too cold
1. Controller in program mode
2. Check controller calibration
3. Faulty contactor (2400E)
4. Faulty controller
5. Faulty temperature sensor
probe
6. Faulty gas valve (2400GH)
7. Faulty element(s) (2400E)
1. Exit program mode
2. See CALIBRATION
3. Replace
4. Replace
5. Replace
6. Replace
7. Replace
