Brooks 9600 - On-Board;Cryo Electrical Module Legend

D-2 ©2013 Brooks Automation Inc. Pub. No. 8040444, Rev. AA, 01/14/2013 ECO No. 63723
J11 Open
J12 Module Signal Connector
J13/P13 Phase Monitor
J14 Open
J15 Cryo Power Output
K2 Over Temperature Lockout Relay
Table D-3: On-Board/Cryo Electrical Module P/N 8135127G001 Legend
Identifier Description
JT1 Open
JT2 Open
JT3/PT3 T2 Cold Head Supply, 2 phase
JT4/PT4 T1 Cold Head Supply, 2 phase
JT5/PT5 T2 Cold Head Transformer Output
JT6/PT6 T1 Cold Head Transformer Output
JT7/PT7 T3 Supply
JT8/PT8 T3 Low Voltage Output (23/26 VCT)
J18 Power Output
J19 Signal Output
P12 Signal Connector
P15 Power Connector
K1 Cold Head Voltage Relay
K2 Signal Voltage Relay
K3 Cryo Power Relay
T1 Cold Head Supply
T2 Cold Head Supply
T3 Low Voltage Supply
Table D-2: Basic Control Assembly Legend (Continued)
Identifier Description
