©2013 Brooks Automation Inc. Pub. No. 8040444, Rev. AA, 01/14/2013 ECO No. 63723 1-9
9600 Compressor Installation, Operation and Maintenance Instructions
System Circuit Breaker
The System Circuit Breaker protects main input power to the Compressor
pump and module. The circuit breaker positions are labeled ON (1), which
is in the UP position, and OFF (0), which is in the DOWN position.
NOTE: The phase monitor in the Compressor will cause the system circuit
breaker to open when input power phases are incorrect.
Elapsed Time Meter
The Elapsed Time Meter records the number of Compressor operating
hours. Since the meter is digital, it is not illuminated unless the system
circuit breaker is in the ON position and power is connected to the
Compressor. The Elapsed Time Meter maintains the correct accumulated
operating hours while system power is turned OFF.
NOTE: The meter cannot be reset.
Control Circuit Breaker
The Control Circuit Breaker provides current overload protection for all
internal components of the Compressor except the Compressor motor. The
Compressor motor is protected by a separate overload protector. The
Control Circuit Breaker opens automatically and must be reset manually.
Power ON Indicator
The Power On Indicator illuminates when the system circuit breaker is
placed in the ON position. The Compressor pump is energized when the
power indicator is illuminated and the elapsed time meter records system
operation time.
Gas Charge Flared Fitting
The Gas Charge Flared Fitting is used to connect a 99.999% pure helium
supply to the Compressor when helium charging is required. The fitting
has a 45
º
flare and 7/16 in. x 20 threads/inch.
Refer to “Section 5 - Maintenance” for information on adding helium to the
Compressor.
